Classic Project|Chaoma Intercity Railway-Maanshan Yangtze River Highway Thiab Railway Choj
Nov 30, 2022
Niaj hnub no, Chaoma Intercity Railway - Ma'anshan Yangtze River Highway thiab Railway Choj tau xaj 34 teeb ntawm Hanpu hluav taws xob wrenches, 2 teeb ntawm cov khoom siv hluav taws xob torque ntes, thiab 8 teeb hluav taws xob tswj kev xa khoom. Qhov project tau ua los ntawm Tuam Tshoj Railway Choj Bureau.
Kev ua haujlwm yog tus qauv, thiab kev ua haujlwm hnyav yog lub xeev. Cov neeg ua haujlwm hauv lub rooj sib txoos ntawm Shandong Hanpu sib sau ua ke cov tshuab txiav txim thiab ua qhov kawg kev tshuaj xyuas thiab kev sim kom ntseeg tau tias kev ua haujlwm thiab kev ua haujlwm zoo ntawm cov tshuab thiab ua neej nyob raws li kev xaiv ntawm txhua tus neeg siv khoom.
▲ Kev txiav txim tshuab
▲ Cov neeg ua haujlwm kuaj xyuas lub tshuab
Cov neeg ua haujlwm tau ntim cov tshuab ua ke thiab kuaj xyuas, uas yuav ua lub luag haujlwm tseem ceeb hauv kev tsim kho tus choj.
· Cov qauv thiab cov khoom tsis raug txiav txim rau Chaoma Intercity Railway Project
Qauv | PN -7 | TN -12 | PN -12 | TN -21 |
Freq | 50-60HZ | 50-60HZ | 50-61HZ | 50-60HZ |
Qhov hluav taws xob | 230V/115V | 230V/115V | 230V/115V | 230V/115V |
Max tam sim no | 6A/12A | 8A/16A | 7A/14A | 8A/16A |
Kev siv hluav taws xob Max | 1300W | 1800W | 1650W | 1800W |
Torque Range | 300-700N.m | 500-1200N.m | 500-1200N.m | 900-2100N.m |
Ro ceev (min{0}}) | 15rpm ua | 9rpm ua | 12.5rpm ua | 6rpm ua |
Qhov hnyav (lub cev loj) | 4.5 KG | 5.5 KG | 5.3KG ib | 6.6KG ib |
Tiv thaiv Class | Ob chav rwb thaiv tsev | Ob chav rwb thaiv tsev | Ob chav rwb thaiv tsev | Ob chav rwb thaiv tsev |
Hloov tau Bolts Dia | M24 intialtihtening | M24 zaum kawg | M27 M30 intialtihtening | M27 M30 zaum kawg |
Qauv | Max Torque | Kev kuaj pom ntau | Precision | Gear Ratio | Qhov hnyav | Square Tsav |
SF -1200 | 1200N.m | 50-1200N.m | ± 3 feem pua | 1:16 | 4 KG | 1/2" |
SF -2100 | 2100N.m | 50-2100N.m | ± 3 feem pua | 1:20 | 4.6 KG | 1/2" |
SF -3500 | 3500N.m | 50-3500N.m | ± 3 feem pua | 1:35 | 5.5 KG | 1/2" |
SF -5000 | 5000N.m | 100-5000N.m | ± 3 feem pua | 1:15 | 16 KG | 3/4" |
SF -10000 | 10000N.m | 200-10000N.m | ± 3 feem pua | 1:17 | 16 KG | 3/4" |
SF -20000 | 20000N.m | 500-20000N.m | ± 3 feem pua | 1:24 | 47.6 KWG | 3/4" |
Chaoma Intercity-Ma'anshan Yangtze River Highway thiab Railway Choj
Tshooj Jiangnan ntawm Chaoma Intercity Railway (xws li Maanshan Yangtze River Railway Choj) pib ntawm Chaohu Lake mus rau qhov kawg ntawm Jiangbei seem ntawm Maanshan Intercity Railway, hla dhau Maanshan Yangtze River Railway Choj, thiab xaus ntawm Ma' anshan South chaw nres tsheb. Txoj kab tseem ceeb yog 13.367 km ntev. Tib lub sijhawm, 11. . Tus choj yog tsim raws li tus qauv ntawm plaub-kab railway thiab ob-txoj kev rau-txoj kab hauv nroog txoj kev, thiab qhov kev sib koom ua ke yog 9.799 km ntev. Ntawm lawv, tus choj tseem ceeb nyob rau sab laug ceg ntawm tus Dej Yangtze siv peb lub tsev steel truss cable-nyob choj nrog lub ntsiab ntawm (2 × 1120) meters thiab tag nrho ntev ntawm 3360 meters. Tus choj txuas txuas nrog qhov ntev tshaj plaws sib koom ua ke thiab qhov siab tshaj plaws ntauwd. Kev kwv yees tag nrho cov peev ntawm Jiangnan seem yog 16.435 billion yuan, thiab tag nrho cov peev ntawm tag nrho cov kab yog 25.344 billion yuan. Lub sijhawm tsim kho yog 5 xyoos. Tom qab ua tiav, Tuam Tshoj Railway Shanghai Bureau Group Corporation yuav raug tso siab rau kev ua haujlwm thiab kev tswj hwm.
Ma'anshan Txoj Kev Loj-Railway Yangtze River Choj yog ib txoj haujlwm tswj kev tsim kho tshiab Chaoma Intercity Railway. Nws yog lub ntiaj teb thawj tus choj peb-ntaus cable-nyob nrog ib qhov ntev ntawm tshaj 1,000 meters. Rub tus choj yuav tsim 7 ntiaj teb cov ntaub ntawv tom qab ua tiav.
Raws li thawj qhov kev sib tw tsheb ciav hlau sib koom ua ke los ntawm cov xeev thiab nroog hauv Anhui Xeev, Chaoma Intercity Railway txuas nrog Shanghe-Hangzhou high-speed railway nyob rau sab qaum teb thiab cov kev sib tshuam raws tus dej nyob rau sab qab teb ntawm Jiangsu. Nws tsis yog tsuas yog ib qho kev sib txuas ncaj qha ntawm Maanshan thiab Hefei, lub xeev lub nroog, tab sis kuj yog qhov tshiab kev tsheb ciav hlau ceev ceev hauv Shanghai thiab lwm lub nroog hauv Yangtze River Delta yog qhov tseem ceeb tshaj plaws los txhim kho cov txheej txheem ntawm cheeb tsam siab. Txoj kev tsheb ciav hlau ceev ceev, txhim kho kev thauj mus los ntawm cov channel, thiab txhawb kev txhim kho kev sib koom ua ke ntawm Yangtze River Delta thiab txoj kev loj hlob ntawm Yangtze River Economic Belt.
Shandong Hanpu Machinery Industry Co., Ltd. yog lub chaw tsim khoom siv hluav taws xob kev lag luam nrog R & D, ntau lawm thiab muag khoom. Cov khoom tseem ceeb: hluav taws xob torsional shear wrench, hluav taws xob torque ciaj ntswj, portable bolt torque detector, axial force torque meter, axial force meter Tom qab ntau tshaj 20 xyoo ntawm innovation thiab kev loj hlob, lub tuam txhab tam sim no muaj ib tug 62-acre industrial park thiab 30, 000 square metres ntawm kev tsim khoom thiab R&D kev cob qhia, thiab tau nthuav qhia ntau cov khoom siv ua haujlwm siab ua hauv Switzerland, Lub Tebchaws Yelemees, thiab Nyij Pooj, dhau los ua lub hauv paus loj ntawm cov khoom siv hluav taws xob hauv Suav teb.
